Upper limb

Wrist radiograph — distal radial fracture

Plain radiograph · Posteroanterior and lateral wrist · Wrist

Before you comment on anything

You met this bone at the osteology bench; here it is on a film. The reason the deformity has a name is anatomical: the distal fragment tilts dorsally, so the wrist takes the shape of a dinner fork from the side. Before you say anything about the fracture, name the carpal rows and check the radial styloid, because that relationship is what surgeons restore.

$Wrist radiograph — distal radial fracture — Plain radiograph, Posteroanterior and lateral wrist$

Plain radiograph · Posteroanterior and lateral wrist · © MedpulseIq.com

Read it in order

0 of 4

Work down the list. The answer unlocks when you have been through all of it.

Sign in to open the rest of this film

The landmarks and the viva deck are free with an account. No card, no trial.

Create a free account

Name the anatomy first

The distal radius and ulna and their articular surfaces
The proximal carpal row — scaphoid, lunate, triquetral and pisiform
The distal carpal row — trapezium, trapezoid, capitate and hamate
The normal downward projection of the radial styloid below the ulnar styloid

Do not confuse it with

A Smith fracture
In a Smith fracture the distal fragment displaces towards the palm rather than the back of the wrist, giving the reverse deformity.
A scaphoid fracture
Tenderness and the fracture line lie in the anatomical snuffbox and the scaphoid waist; the distal radial cortex is intact.

Examiner trap

Reporting the radius and stopping. The scaphoid and the distal radio-ulnar joint must be commented on, because both are commonly injured with it.

Memory hook

Dorsal tilt makes a dinner fork; palmar tilt makes it a Smith.

Senior’s 30-second takeaway

Wrist radiograph — distal radial fracture — the whole bench in four lines. Read this on the way in.

If you see this: Two wrist views with soft-tissue swelling · A cortical break in the distal radius · Dorsal tilt of the distal fragment on the lateral
If asked to identify it: There is a fracture of the distal radius with dorsal displacement of the distal fragment.
If asked one more: The radial styloid normally lies about a centimetre distal to the ulnar styloid.
If asked why it matters: Always check the distal radio-ulnar joint and exclude a scaphoid fracture as well.

Then stop. Let the examiner ask the next question.
