Abdominal radiograph, erect — dilated bowel
Plain radiograph · Erect abdomen · Abdomen
Before you comment on anything
The most useful anatomy lesson on any abdominal film: you can tell small bowel from large bowel by their mucosal folds alone. Valvulae conniventes cross the whole width of the lumen; haustra do not. Learn that one distinction and half of abdominal plain-film reading falls into place. Say the projection first, because it decides what you are allowed to comment on — fluid levels need a horizontal beam.
Plain radiograph · Erect abdomen · © MedpulseIq.com
Read it in order
0 of 6
Work down the list. The answer unlocks when you have been through all of it.
Sign in to open the rest of this film
The landmarks and the viva deck are free with an account. No card, no trial.
Create a free accountSenior’s 30-second takeaway
Abdominal radiograph, erect — dilated bowel — the whole bench in four lines. Read this on the way in.
- If you see this
- Dilated loops in the centre of the abdomen · Folds crossing the full width of the lumen · Little or no gas peripherally in the colon
- If asked to identify it
- There are centrally placed dilated loops whose mucosal folds cross the entire lumen.
- If asked one more
- Valvulae conniventes cross fully; haustra do not, because the taeniae coli sacculate the colon.
- If asked why it matters
- Dilatation that stops at a point suggests a mechanical cause rather than ileus.
Then stop. Let the examiner ask the next question.
